Main technical parameters:
model |
VSI5X7615 |
VSI5X8522 |
VSI5X9532 |
VSI5X1145 |
|
Throughput capacity (t/h) |
Center and Ring feeding |
150~280 |
240~380 |
350~540 |
500~640 |
Center feeding |
70~140 |
120~190 |
180~280 |
250~360 |
|
Max. Feed Size (mm) |
Soft material |
<35 |
<40 |
<45 |
<50 |
Hard material |
<30 |
<35 |
<40 |
<45 |
|
Rotation speed (r/min) |
1700~1900 |
1500~1700 |
1300~1510 |
1100~1310 |
|
Power of double motor (KW) |
150 |
220 |
320 |
440 |
|
Overall dimension L×W×H (mm) |
4100×2330× |
4140×2500× |
4560×2600× |
5000×2790×3320 |
|
Weight (t) |
8.6 |
11.8 |
17.5 |
27.5 |
|
Power source |
380v,50Hz |
||||
Thin oil lubrication station |
Power for double oil pump |
2 x 0.37 KW |
|||
Safety |
To make sure the supply of oil with double oil pump, working without oil, temperature when water cools, start the motor by heating it in winter. |
||||
Power for oil box heater |
2 KW |
||||
Overall dimension L×W×H (mm) |
820×520×1270 |
Note: Capacity depends on crushing limestone, material size, moisture and features also affect capacity.
